WAY too verbose couple of examples of estimating SoH (and a bit circular in reasoning perhaps) from either your known Soh (OBDII or PPIWIS) or from total kWh used to charge your the car if known/recorded (my EVSE ChargePoint does a nice job of this).Ok. @Archimedes posted elsewhere that he believes Taycan's miles per kwh consumption reports are higher than his actuals.
The very last section might (or not) address your query?
___________________________________
New-battery usable kWh is 86 kWh (vs Porsche published 83.7) - See BaselIne Thread Post 1.
My latest measured Soh of 88%.
Using these values alone to estimate current available (degraded) kWh = 86 * 0.88 = 75 kWh usable
For completeness, if I use the Porsche pubished 83.7 usable kWh this = 73.7 kWh
____________________________
Now we can also determine Soh from total EVSE/DC charge-in in kWh but this method must also account for losses during the charging process /other effects.
Charge-in energy losses
My car’s average efficiency (from MyPorsche) = 36.7 kwh/100 mi over 7668 mi driven.
Total kWh less charging losses over 7668 miles = 3500.6/.367 = 2814.2 kWh
i.e. 686 kWh or 20% of charge-in is reported as losses (i.e. not used to propel the car forward).
Knowing this we can calculate Soh from total EVSE energy with 20% losses:
(kWh input * 0.8) /((end Soc-start Soc)/100))
Using this on a single charge event example from my car:
I put 51.9 kWh t recover 58% of my SoC from 27 to 85% Soc
So to calcualte SoH kWh (less losses) at an SoC of 100%:
(Charge-in less losses) / (Amount of SoC change/100) or as in this example:
(51.9 * 0.8) / (85-27 / 100) = 71.5 kWh SoH
Of course just one charge event.
If we use a more conservative 15% for losses (entirely speculative) = 76 kWh Soh.
Rather than use just one charge session, when I look at 21 successive AC home charges in 2023 (again using 20% losses).
I get an average SoH calculation of 77.6 kWh SoH
Compares well to the SoH derived from my OBDII/PIWIS Soh at 75 KWh
_____________________
So if I were to calculate an average efficiency for my car based off total charge-in and NOT take into account charge losses I’d have:
7668/3500.6 = 2.2 kWh per mile.
This is a lower value than the MyPorsche’s estimate which is ca. 2.7 kWh per mile.
However if I now calculate for losses I get:
7668/2814.2 = 2.72 miles per kWh matching the MyPorsche average efficiency.
Cheers, C.
